MuxLab HDMI / RS232 Receiver with PoE (HDBT, UHD-4K)
The HDMI/RS232 Extender Kit (500454-PoE) allows HDMI equipment to be connected up to 131ft (40m) at 4K/30 (4:4:4) or 4K/60 (4:2:0) resolutions, or 230 ft (70 m) at resolutions up to 1080p via one (1) Cat 5e/6 unshielded twisted pair cable in a point-to-point configuration. For ease of cabling the extender kit features PoE (PD), including PoC, on both the transmitter and receiver. The unit supports RS232 and bidirectional IR for end devices remote control. This kit comes with one (1) transmitter, one (1) receiver, one (1) IR Emitter, and one (1) IR sensor.
Applications
- Digital signage, commercial AV systems, classroom projector systems, boardroom systems, collaborative PC systems, medical information systems.
Key Features
- Supports 1080p deep color and full 3D to distances of up to 230 ft (70m) over single Cat5e/6
- Supports 4K @ 24/25/30Hz (4:4:4) and 4K/60 (4:2:0) to distances of up to 131 ft (40m) over single Cat5e/6
- Supports RS232
- Supports Bi-directional IR pass through
- Supports all digital audio modes
- PoE (PD) & PoC on both the transmitter and receiver
- Includes IR emitter and IR sensor (carrier-wave)
- Compatible with 500454 (non PoE version)
Full Mfg Warranty
