MuxLab VGA Balun II Kit
The VGA Balun II eliminates costly and bulky VGA cable, allowing a VGA source to be connected to a VGA monitor via one (1) 4-pair Cat 5 unshielded twisted pair (UTP) cable.
Used in pairs, the VGA Balun II allows VGA video to be transmitted up to 350ft (107m) via Cat 5 at 800 x 600 resolution. The products feature a reset button that may be required when using certain displays.
More information may be found in the product Installation Guide. The VGA Balun II works in conjunction with laptops, PCs, plasmas, CRT, LCD monitors and DLP projectors. Typical applications include digital signage, boardroom systems, classroom video instruction and custom audio-video systems.
*Includes (1) 500040 VGA Balun II, HD15 HD Plug, PC Side & (1) 500042 VGA Balun II, HD15 HD Plug, Monitor Side
FEATURES
- Fully supports Cat5e/6 UTP
- Cost efficient versus VGA cable
- Use existing structured cabling system
- Save conduit space
- Includes (1) 500040 VGA Balun II, HD15 HD Plug, PC Side & (1) 500042 VGA Balun II, HD15 HD Plug, Monitor Side
Key Features
- PC & Monitor Side VGA Baluns Included
- VGA Video Transmission Range up to 350'
- Supports Cat 5e/6 UTP
- Reset Button
The VGA Balun II Kit from MuxLab includes a PC-side VGA balun and a monitor-side VGA balun. The kit enables a VGA source to be connected to a VGA monitor via a 4-pair Cat 5e/6 cable, eliminating the need for an expensive and bulky VGA cable. When used together, the baluns provide VGA video transmission range of up to 350' at 800 x 600 resolution.
MuxLab 500040 VGA Balun II (PC Side)
The MuxLab 500040 VGA Balun II (PC Side) allows a VGA source (PC / laptop) to be connected to a VGA video display device like a CRT, LCD, plasma screen or a DLP/multimedia projector using a 4-pair Cat5E/6 UTP cable. Capable of transmitting SVGA video up to 350' (107m) at 800 x 600 resolution, the PC side balun uses either p/n 500041 or 500042 connector.
The balun II supports wide-screen formats (16:9, 1366 x 768), and features a reset button and a ground screw. The reset button is meant for sync-sensitive displays (used when the VGA source connected to the display is re-started or re-booted) and the ground screw is needed in case of a yellowish hue on the display screen.
Allowing you to replace the bulky VGA cable by space- and cost-saving Cat5E/6 cable, the VGA balun II finds wide application in digital signage, meeting rooms, training rooms, classroom visual teaching aids and other audio-video systems. Use of the VGA balun II (with Cat5E/6 cables) facilitates placing the display device at extended distances from the video source in classroom / training rooms, and helps distribute the display monitors throughout a complex in case of video information setups.
With an ABS fire-retardant plastic enclosure, the balun can be freestanding and comes with a hook and loop fastener for mounting.
- Allows a VGA source (PC / laptop) to be connected to a VGA video display device like a CRT, LCD, plasma screen, or a DLP/multimedia projector using a 4-pair Cat5E/6 UTP cable
- Capable of transmitting SVGA video up to 350' (107m) at 800 x 600 resolution
- Uses either p/n 500041 or 500042 connector
- Cat5E/6 cable are less bulky, less expensive than VGA cables
- Compact size - 19 x 1.75 x 1.5 "(48.26 x 4.4 x 5.1 cm)
- Maximum distance supported via Cat5E/6 for video reception
- VGA - 640 x 480 pixels (15MHz) 450' (137m)
- SVGA - 800 x 600 pixels (30MHz) 350' (107m)
- XGA - 1024 x 768 pixels (60MHz) 250' (76m)
- SXGA -1280 x 1024 pixels (100MHz) 200' (61m)
- WXGA -1366 x 768 pixels 180' (55m)
- ABS fire-retardant plastic enclosure
- Hook and loop fastener included for mounting
MuxLab 500042 VGA Balun II (Monitor Side)
The MuxLab 500042 VGA Balun II (Monitor Side) allows a VGA video display device like the CRT, LCD, plasma screen or a DLP/multimedia projector to be connected to a VGA source (PC / laptop) using Cat5E/6 cable. Capable of receiving SVGA video up to 350' (107m) at 800 x 600 resolution, the monitor side balun uses either a p/n 500041 or a 500042 connector.
The Balun II supports wide-screen formats (16:9, 1366 x 768), and features a reset button and a ground screw. The reset button is meant for sync-sensitive displays (used when the VGA source connected to the display is re-started or re-booted) and the ground screw is needed in case of a yellowish hue on the display screen.
Allowing you to replace the bulky VGA cable by space and cost saving Cat5E/6 cable, the VGA Balun II finds wide application in digital signage, meeting rooms, training rooms, classroom visual teaching aids and other audio-video systems. Use of the VGA Balun II (with Cat5E/6 cables) facilitates placing the display device at extended distances from the video source in classroom / training rooms, and helps distribute the display monitors throughout a complex in case of video information set-ups.
- Allows VGA cable to be replaced by Cat5E/6 cable
- Cat5E/6 cables are less bulky, less expensive than VGA cables
- Receives SVGA video (800 x 600 pixels) up to 350' (107m)
- Works with any equipment that supports VGA, XGA, or SVGA signals - PCs, laptops, multimedia projectors, CRT / LCD monitors, plasma displays, VGA signal boosters / signal splitters / scan converters
- Compact size - 19 x 1.75 x 1.5 "(48.26 x 4.4 x 5.1 cm)
- Maximum distance supported via Cat5E/6 for video reception
- VGA - 640 x 480 pixels (15MHz) 450' (137m)
- SVGA - 800 x 600 pixels (30MHz) 350' (107m)
- XGA - 1024 x 768 pixels (60MHz) 250' (76m)
- <\li>SXGA -1280 x 1024 pixels (100MHz) 200' (61m)
- WXGA -1366 x 768 pixels 180' (55m)
- ABS fire retardant plastic enclosure
- Hook and loop fastener mounting pad included
